Room Temperature UV Sterilizer Cabinet | Timer Setting for Household & Salon Disinfection

1、 Product parameters
Product Name: UV Disinfection Cabinet
Model: FY-9181
Capacity: 14L
Installation method: cabinet type
Brand: Other
Appearance: Single door
Disinfection method: UV+trace ozone sterilization
Disinfection time: 15, 30, 45, 60 minutes
Drying time:——
Power supply voltage: 110-250V
Rated power: 6W
European standard – rated voltage: 220-240V 50Hz
US Standard – Rated Voltage: 110-120V 60Hz
Origin: Foshan City, Guangdong Province
Net weight (single unit): 2.8KG
Product size: 20.5 * 23 * 38.5cm
Gross weight: 3.3KG
Product packaging size: 41 * 29 * 26cm
Large box quantity: No large boxes available
Large box size: None
Gross weight of the whole box: none
Stacking layers: 2 layers
Control mode: mechanical switch
Washing method: wiping
Opening and closing method: front opening
Product List: Host * 1+Rack * 1+Tray * 1
Material: Metal+Plastic (Panel: Steel Plate Spray Paint)
Target audience: General population
Origin: Foshan, Guangdong
Specifications: European standard 220V, American standard 110V
Color classification: White
Packaging type: Basic packaging

2、 Product Special
Instructions for use
1). Place the tools to be disinfected into the instrument, close the door, and plug in the power cord.
2). Turn on the timer switch, select the function, and the disinfection cabinet will start working.
3). After the time is up, the disinfection will be automatically completed and turned off. Afterwards, only the disinfected items need to be taken out.

Applicable items
-Suitable for nail tools, dental tools, tea sets, towels, masks, glasses, keys, tableware, underwear, clothing, watches, mobile phones, bottles, jars, scissors, combs, makeup brushes, dentures, and all other items.

Items that can accept room temperature light disinfection and ozone disinfection can choose to use only one lamp tube for disinfection when disinfecting a small amount of items.
Items that can accept light disinfection and 80 ℃ hot air drying (pasteurization) for disinfection.

Applicable scenarios
Suitable for various scenarios, such as beauty salons, hair salons, barber shops, nail salons, skin management centers, hotels, pedicures, hospitals, clinics, dental clinics, home use, tattoo shops, eyelash salons, piercing shops, pet shops, dental clinics, tattoo shops, etc. All items that can accept room temperature light disinfection and ozone disinfection. When disinfecting a small amount of items, you can choose to only turn on one of the light tubes for disinfection.

3、 Introduction to Disinfection Principles

Ultraviolet Disinfection
-The core principle of ultraviolet disinfection is to destroy the genetic material (DNA or RNA) of microorganisms, causing them to lose their ability to reproduce and survive, thereby achieving the effect of sterilization and disinfection.
Specifically, ultraviolet light (especially the UVC band with wavelengths between 200-280nm, also known as “bactericidal ultraviolet light”) can penetrate the cell membrane of microorganisms and act on their internal nucleic acids
Formation of pyrimidine dimers: Ultraviolet radiation can crosslink thymine (or uracil) bases in DNA or RNA molecules, forming dimers. This structure will disrupt the normal base pairing rules of nucleic acids.
Blocking the transmission of genetic information: Damaged nucleic acids cannot replicate and transcribe normally, and microorganisms cannot divide to produce new individuals or synthesize proteins that sustain life activities. Eventually, they will die or become inactive due to metabolic disorders and inability to reproduce.
In addition, ultraviolet radiation can also damage the cell membrane and enzyme system of microorganisms, further enhancing the disinfection effect. However, its disinfection effect is affected by factors such as UV intensity, irradiation time, microbial species, and environmental obstructions.

Tip: UVC ultraviolet rays are harmful to human skin and eyes, and protection should be taken when using them.

Ozone Disinfection
-The core principle of ozone disinfection is to utilize the strong oxidizing properties of ozone to destroy the cell structure and biomolecules of microorganisms, thereby achieving the effect of sterilization and disinfection.

The specific mechanism of action can be divided into the following aspects:

1. Oxidative damage to cell membrane**
   Ozone (O3) has extremely strong oxidizing ability and can undergo oxidative reactions with lipids (such as phospholipids and unsaturated fatty acids) on microbial cell membranes, disrupting the integrity and permeability of the cell membrane, leading to leakage of core substances such as proteins and nucleic acids inside the cell, and the loss of the foundation of microbial life activities.
2. * * Degradation of biomolecules**
   -For * * protein * *: Ozone can oxidize functional groups such as peptide bonds and thiol groups (- SH) in protein molecules, causing denaturation, coagulation, and loss of enzymatic activity and physiological functions of the protein;
   -Ozone can oxidize the phosphodiester bonds and bases on the nucleic acid chain, damaging the genetic structure of nucleic acids and preventing microorganisms from replicating and reproducing.
3. * * Decompose harmful organic compounds**
   In addition to sterilization, ozone can also oxidize and decompose some organic pollutants in water or air (such as formaldehyde, benzene, ammonia, etc.), converting them into harmless or low toxic substances (such as CO ₂, H ₂ O), which have both disinfection and purification effects.
